It depends on whether the components are connected in series or in parallel and at which point the output voltage is tapped. Due to the different connections of resistor and capacitor, various filters can be realized. It is easier to work with the circuits using our RC filter calculators. Depending on the circuit, the RC filter can be calculated according to different formulas, but the time constant of the RC filter is calculated identically for each one. This is calculated based on resistance and capacity and indicates the required charging time. The function of the capacitor also makes the time constant of the RC filter important. Depending on the interconnection, the formulas change for the calculation, but these two variables always play a role. The interaction of these two elements results in the desired filter effect. When calculating the RC filter, the resistance and capacitance are most important. RC filter resistance, capacity and time constants
The lower the frequency, the longer the charge cycles and the larger the capacitive reactance $X_C$. This effect arises from the fact that the capacitor is permanently charged and discharged by changing the poles. However, if it is connected to an AC voltage, it forms a capacitive reactance $X_C$, which changes depending on the voltage. With DC voltage, it will charge itself and represent a break in the circuit when fully charged. The capacitor C, however, works like a battery with a very small capacity.
